Perfect partners.
Edge systems are designed to work in perfect synchronisation. Match the Edge W with our most versatile Preamplifier Network player, Edge NQ, to create a hi-fi system with a sound, and a look, unlike anything else.
Specifications
Continuous power output
100W RMS into 8 Ohms; 200W RMS into 4 Ohms
THD (unweighted) <0.002% 1kHz at rated power (8 Ohms); <0.02% 20Hz – 20kHz at rated power (8 Ohms)
Frequency response <3Hz – >80kHz +/-1dB
S/N ratio (ref 1W into 8 Ohm) >93 dB
S/N ratio (ref full power) >113 dB
Crosstalk @ 1kHz
< -100dB
Input sensitivity Input A1-A2 (unbalanced)
1.09V RMS
Input impedances Input A3 (balanced) 47k Ohm; Input A1-A2 (unbalanced) 47k Ohm
Inputs Balanced, Unbalanced
Outputs Speakers, Loop out
Max power consumption 1000W
Standby power consumption <0.5W
Dimensions 150 x 460 x 405mm (5.9 x 18.1 x 15.9")
Weight
23.6kg (51.9lbs)
In the box 1000W
Standby power consumption <0.5W
Dimensions (W x H x D) 76 x 430 x 340mm
Weight
8.3kg (18.3lbs)
