Specs
Frequency response : 1 Hz to 200 kHz
Total harmonic distortion :
0.01 %
Maximum output before clipping : +/-12 V peak
Gain : Magnetic phono stage +33dB (MM) at 1 kHz, High level stage +20dB (line)
Slew capability : Max. Voltage slewing rate 150 V/microsecond (resistively loaded)
Signal to noise ratio : 82dB (line)
Output : 3 V (Pre out), 12 V (Pre out Max)
Dimensions (WxHxD), inches : Front plate 19 x
2.62, Chassis 17 x
2.215 x 8, Power supply 8 x
3.375 x 5
